Board & Batten Woodgrain Steel Siding

True Wood Grain Textures in 24 Gauge Steel

Wood Grain Steel Metal Siding

A Vibrant New Aesthetic in Linial Steel Cladding

Modern Steel Woodgrain Board and Batten cladding offers a vibrant new aesthetic in lineal steel cladding. Kynar-finished 24-gauge steel is maintenance-free and warranted for 30 years.

  • Competitive installation cost, lower lifetime cost, and zero maintenance.
  • Two coverage widths: 9.75” and 13.5”, providing a 2.25” long batten.
  • Panel depth of 1/2” keeps it flush with other popular cladding profiles.
  • Easy installation with a clip system and no exposed fasteners.

9.75″ Panel Profile

Wood Grain Steel Board and Batten Profile

13.5″ Panel Profile

Forma Steel Board and Batten from Modern Materials

Specifications

  • Wall Coverage: 9.75″ or 13.5″

  • Hidden Fastener Panel

  • Available in Lengths: 62″ up to maximum of 322″

  • 24″ to <62″ Lengths available for Cut Charge

  • Installed on a floating clip system for ideal thermal expansion and contraction

  • Please Note: 9.75″ Coverage Custom Lengths Should Be Ordered in Multiples of 4

  • Please Note: 13.5″ Coverage Custom Lengths Should Be Ordered in Multiples of 3

  • Substrate: Minimum of 1/2″ Plywood
